10 x 5 Tandem Axle Box Trailer
$6,690.00
Heavy-duty 3.05 × 1.52 m tandem box trailer with a fully welded RHS chassis and 2.5 mm checker-plate floor. Rated at 2 T ATM with ~580 kg tare, mechanical brakes, and 8″ jockey wheel. Features include 300 mm drop-down sides, solid axles, LED lights, and full tie-rail provisions. Kindly verify specifications when ordering.
Description
Description
| Specification | Details |
|---|---|
| ATM / GVM: | 2 000 kg |
| TARE: | ~580 kg |
| Internal Size: | 3 050 × 1 520 × 300 mm |
| Drawbar: | 1 950 mm long, 100 × 50 × 3 mm RHS |
| Chassis: | Fully welded on 100 × 50 mm RHS frame |
| Floor & Sides: | 2.5 mm checker-plate floor & 300 mm fully welded drop-down sides/tailgates |
| Axles: | Dual 50 mm solid (or 45 mm) axles on 6‑leaf rocker‑roller springs |
| Brakes: | Mechanical disc / override brake |
| Wheels & Tyres: | 14″ Sunraysia rims with 185 R14 light‑truck tyres |
| Jockey Wheel: | 8″ swing-up heavy-duty |
| Lights & Plug: | LED tail/side lights, flat 7‑pin plug |
| Extras: | Tie rails all around, side-steps, ladder rack holders, compliance plate, mudflaps |
