8×5 Deluxe Heavy Duty Cage Trailer (Tandem Axle)
$4,950.00
Premium 8×5 tandem-axle galvanised cage trailer available with 600 mm or 900 mm removable cage, ladder racks, and slide-under ramps. Built with hot‑dipped galvanised steel and checker‑plate body, with up to 2,800 kg ATM depending on configuration. Features include override brakes, rock-roller suspension, full tie‑down rails, LED lighting, and Sunraysia-style wheels. Ideal for heavy-duty, trade, or commercial use. Kindly verify specifications when ordering.
Description
Description
| Specification | Details |
|---|---|
| Trailer Size | 8 ft × 5 ft (≈ 2.44 × 1.52 m) |
| Axle Configuration | Tandem Axle |
| ATM / GVM | Approx. 2,000–2,800 kg (depending on model) |
| Construction | Hot‑dipped galvanised, fully welded chassis & body |
| Floor & Side Panels | 2.5 mm checker‑plate throughout; ~300 mm sides |
| Cage Height | 600 mm or 900 mm removable galvanised cage with front/rear gates |
| Ladder Racks | Slide‑in / slide‑out racks included |
| Ramps | Slide‑under checker‑plate ramps included |
| Suspension | Rock‑roller springs (6–7 leaf options) |
| Brakes | Mechanical override standard; electric/hydraulic upgrades available |
| Axles | Dual solid round or square axles (40–45 mm) |
| Drawbar & Chassis Reinforcement | 100×50 mm RHS drawbar, 300 mm cross‑member spacing, underfloor supports |
| Tie‑Down Rails | All around tray and over guards |
| Wheels & Tyres | 14″ Sunraysia-style rims with light-truck tyres |
| Jockey Wheel | Swing‑up model included |
| Lighting & Plug | ADR-compliant LED tail lights; 7‑pin flat or round plug |
| Tailgates | Front & rear fold-down/removable gates |
